MIMAKI CF2 Series User Manual

5-6
No-plotting area around the register marks
There must be no data or stain arround the register mark; otherwise a wrong origin may be detected or a mark read
error can occur.
• If a wrong mark origin is detected, the cutting will be performed in a wrong area.
10mm
10mm
Squaremarksize(5to30mm)
SquareMark
Squaremarkorigin
No-plottingarea
Single
Double
ᵫᵿᶐᶉ
ᵭᶐᶇᶅᶇᶌ
ᵫᵿᶐᶉ
ᵭᶐᶇᶅᶇᶌ
Mark MarkNo plotting area
Mark size
Mark size
