2-9
FIXING A WORK
A work can be fixed on the device following one of the two procedures described below.
• Fixing the work with vacuum
• Fixing the work with adhesive tape
Four area marker labels are attached to the cutting panel under the felt mat. The area within the labels is the maxi-
mum effective cutting area in which cutting can be performed. Fix a work within this area.
Cutting cannot be mechanically performed in any area outside the area marker labels.
Fixing a work that is comparatively light in weight
A work that is comparatively light in weight such as thin coated board or corrugated fiberboard is vacuum-sucked for
the securing.
1. Place a work on the cutting panel.
• Thickness of works that can be attached on this device should not exceed 20mm.
• Optional blower is required to use the vacuum function.
• If a work is too small to cover all suction holes, cover all the holes with a sheet.
If any of the suction holes is not covered, the suction force will decrease to fail to secure the
work.
To Next Page
