3-16
Dotted lines or blurred lines are plotted
There is no reciprocal vibration
Cause Corrective measure Reference page
Has the screw in head A loosened? Firmly re-tighten the screw in the head A.
P. 2-15
Is the plotting speed too high? Decrease the plotting speed.
P. 2-25
Is the plotting pressure insufficient? Increase the plotting pressure.
P. 2-25
Has the pen run out of ink? Replace the pen with a new one.
P. 2-15
Cause Corrective measure Reference page
Is the axis of reciprocal vibration sufficiently
lubricated?
Apply a small amount of grease to the axis.
P. 7-17
Is vibration set to "OFF"? Set vibration to a setting from 1 to 5. If recov-
ery is not achieved, contact the store of pur-
chase or a Mimaki sales office.
P. 2-24
To Next Page
