MIMAKI CF2 Series User Manual

1-20
8. Set the [HANDSHAKE] to one of the following.
Hardware, X code, E/A, software*1
*1: [ENQ-ACK] and [SOFTWARE] can be selected when
MGL-IIC3 command has been selected through command
setting for the operation mode.
To return to the previous page, press the key.
9. Enter the input values.
Press the key to enter the input values.
If you do not enter the input data, press the key.
Rendering the set values on the personal computer effective [MODE SET] > [CMD SW]
The set values (commands) that are rendered effective are specified either those set on the operation panel or those set
on the CAD.
Set values
VALID: If items that are set on the operation panel of this device can also be set on the CAD, the latest
command specified is given priority. If the device receives data set on the CAD after the data
have been set on the operation panel, the data received will be given priority.
INVALID: Commands that are set on the operation panel of the device are given priority while ignoring
commands set on the CAD.
1. Press the key several times until the LCD indicates
page 3 of the LOCAL MENU.
2. Select the [MODE SET].
3. Press the key several times until the LCD indicates
page 3 of the [MODE SET].
4. Set the [CMD SW] to one of the following.
VALID , I N VALID
＜ INTERFACE ＞ ２ ／ ２
PARITY ODD ＞
STOP BITS ∗2＞
HANDSHAKE *HARD ＞
＜INTERFACE＞ ２／２
PARITY ODD ＞
STOP BITS 1 ＞
HANDSHAKE XCODE ＞
［LOCAL］ ３ ／ ４
INTERFACE ――― ＞
MODE SET ――― ＞
SELF TEST ――― ＞
［LOCAL］ １ ／ ４
TOOL SELECT ――― ＞
CONDITION ――― ＞
TEST CUT ――― ＞
［LOCAL］ ３ ／ ４
TOOL SELECT ――― ＞
MODE SET ――― ＞
SELF TEST ――― ＞
＜MODE SET＞ ３／６
Z STROKE ∗ 7mm ＞
MULTI-PASS ――― ＞
バキューム ＊オー ト オ フ＞
＜MODE SET＞ ３／６
ROTATE ∗ +90° ＞
COMMAND Ｍ Ｇ Ｌ - Ｉ Ｉ Ｃ ３ ＞
CMD SW ∗ INVALID ＞
