MIMAKI CF2 Series - Effective Cutting Area

1-4
EFFECTIVE CUTTING AREA
The maximum effective cutting areas by the models of devices are given below.
The maximum cutting area does not change by the models of heads (RC-head and RT-head)
Model name X axis (mm) Y axis (mm)
Mark sensor Equipped
Model
CF2-0912 1170 900
CF2-1215 1470 1200
CF2-1218 1770 1200
Mark sensor not equipped
Model
CF2-0912 1200 900
CF2-1215 1500 1200
CF2-1218 1800 1200
Maximum effective
cutting area
Y axis
X axis
