2-10
2. Press the key.
The VACUUM lamp lights up (in green).
The vacuuming unit actuates to pick the work by suction.
Fixing heavy-weight packing etc.
A work such as a heavy-weight packing or industrial rubber may not be sufficiently secured by vacuum-suction. In
this case, secure the work with adhesive tape.
1. Fix four sides of the work with adhesive tape.
• By aliging the mdia edge to the media
guide, work can be set straight. Be sure
to set the work within the Maximum
effective cutting area.
• When EXPAND is set to ON with a
sensor model or No sensor model,
work guide may interrupt the maxi-
mum cutting area. Remove either work
guide plate, or work guide pin.
• Use such adhesive tape that adhesive glue or tape will not remain on the cutting panel.
To Next Page
