MIMAKI CF2 Series User Manual

1-19
Matching the functions of the device to the specifications of the computer
The following explains how to set the functions required to connect the device to your personal computer.
Setting communication conditions [INTERFACE]
Communication conditions for the communication between the device and the computer to which the device is con-
nected by way of RS232C.
Set values
Baud rate: 1200, 2400, 4800, 9600, 19200 (bps)
Data bit: 7, 8 (bit)
Parity: NO PARITY, EVEN, ODD
Stop bit: 1, 2, (bit)
Handshake: Hardware, X code, E/A, software
1. Press the key several times until the LCD indicates
page 3 of the LOCAL MENU.
2. Select the [INTERFACE] from the menu.
3. Set the [BAUD RATE] to a desired value.
The value marked with an asterisk (*) is the current set value.
1200, 2400, 4800, 9600, 19200 (bps)
4. Set the [DATA BITS] to one of the following.
7, 8 (bit)
5. Press the key until the LCD indicates page 2 of the
[INTERFACE].
6. Set the [PARITY] to one of the following.
NO PARITY, EVEN, ODD
7. Set the [STOP BITS] to one of the following.
1, 1.5, 2 bit
［LOCAL］ １ ／ ４
TOOL SELECT ――― ＞
CONDITION ――― ＞
TEST CUT ――― ＞
［LOCAL］ ３ ／ ４
INTERFACE ――― ＞
MODE SET ――― ＞
SELF TEST ――― ＞
＜ INTERFACE ＞ １ ／ ２
RESERVE
BAUD RATE ＊９６００＞
DATA BITS ＊ ８ ＞
＜INTERFACE＞ １／２
RESERVE
BAUD RATE １９２００＞
DATA BITS ＊ ８ ＞
＜ INTERFACE ＞ １ ／ ２
RESERVE
BAUD RATE １９２００＞
DATA BITS ７ ＞
＜INTERFACE＞ ２／２
PARITY ∗ NON ＞
STOP BITS ∗2＞
HANDSHAKE ∗ HARD ＞
＜ INTERFACE ＞ ２ ／ ２
PARITY ODD ＞
STOP BITS ∗2＞
HANDSHAKE *HARD ＞
