MIMAKI CF2 Series User Manual

Matching the functions of the device to the specifications of the computer
1-23
Setting the resolution (GDP) [MODE SET] > [GDP]
Set the resolution of the device to that of your CAD. Refer to the operation manual for your CAD for the resolution
supported by the CAD.
GDP: Graphic Display Pitch
Set values
0.025 mm : The resolution is set to 0.025 mm.
0.010 mm : The resolution is set to 0.010 mm.
1. Press the key several times until the LCD indicates
page 3 of the LOCAL MENU.
2. Select the [MODE SET].
3. Press the key several times until the LCD indicates
page 4 of the [MODE SET].
4. Set the [GDP] to on of the following.
Press the key to change the selected item alternately.
0.025mm, 0.010mm
5. Enter the input values.
Press the key to enter the input values. If you do not enter the
input data, press the key.
［LOCAL］ １ ／ ４
TOOL SELECT ――― ＞
CONDITION ――― ＞
TEST CUT ――― ＞
［ LOCAL］ ３ ／ ４
INTERFACE ――― ＞
MODE SET ――― ＞
SELF TEST ――― ＞
＜MODE SET＞ １／６
Z STROKE *7ｍｍ ＞
MULTI–PASS ――― ＞
VACUUM ＊ AutoOFF ＞
＜MODE SET＞ ４／６
OH UNIT ∗ INIT val ＞
ORIGIN ∗ CENTER ＞
Ｇ Ｄ Ｐ ∗ 0.025 mm ＞
＜MODE SET＞ ４／６
OH UNIT ∗ INIT val ＞
ORIGIN ∗ CENTER ＞
Ｇ Ｄ Ｐ 0.1010mm ＞
［LOCAL］ ３ ／ ４
INTERFACE ――― ＞
MODE SET ――― ＞
SELF TEST ――― ＞
