LOCAL/REMOTE MODES
The operation mode is changed over alternately between the LOCAL mode and the REMOTE mode every time the
key is pressed.
LOCAL mode and the indication on the LCD
Under LOCAL mode, the head travels, functions of the device are set, and data from the personal computer are
received.
All keys on the operation panel are rendered operative under the LOCAL mode.
Under the LOCAL mode, the following three different kinds of indications are given on the LCD.
LOCAL menu: Function name selecting screen
This screen appears when the power to the device is turned on. The main menu consists of four pages.
Sub menu 1: Set value inputting screen
This screen appears after a function has been selected on the main menu using the corresponding function key.
A set value can be input on this screen using function keys.
The asterisk (*) mark given on the left of the set value indicates that the value is currently valid.
Sub menu 2: Function executing screen
A function is executed on this screen. Functions that can be executed include “test cut,” “data clear” and
“automatic judgment of communication conditions.”
[LOCAL[ LOCAL] １ ／ ４
TOOL SELECT ――― ＞
CONDITION ――― ＞
TEST CUT ――― ＞
Indicates that the device is
under the LOCAL mode.
Indicates the name of function
Indicates the page number of the
main menu.
Indicates the function keys to be
used to select the function.
< INTERFACE > １ ／ ２
RESERVE
BAUD RATE ＊９６００＞
DATA BITS ＊ ８ ＞
Indicates the name of
function that has been
selected.
Indicates the page number of the sub
menu.
Indicates the function keys to be used
to select the function.
< TEST CUT > １ ／ １
END KEY to START
CE KEY to CANCEL
Indicates the name of
function that has been
selected.
Indicates the execution key.
Indicates the cancel key.
