TOOLS ARE NOT ALIGNED TO EACH OTHER [TOOL SELECT]
If a plotting tool and a cutter or a plotting tool and a creasing roller fail to finish patterns that lack in overlapping, the
deviation between the tools has to be adjusted.
To adjust the alignment of each tool, use “adjustment of the cutter” and “adjustment of the roller” among the “TOOL
SELECT” functions.
To execute the tool adjusting function, set the speed and acceleration of each tool as described below. If the speed and
acceleration are too high, adjustments cannot be carried out with accuracy.
Speed .................. 20 cm/s
Acceleration ....... 0.1 G
Flowchart of checking and adjusting procedures
General explanation of the adjustment of tools
Tools are adjusted with respect to the below-stated three items.
(1) “Adjustment of the cutter” to adjust the low-pressure tangential cutter.
(2) “Adjustment of the roller” to adjust the rollers and “adjustment of the cutter” for the highpressure tangen-
tial cutter
(3) “Adjustment of the circle θ” to adjust the tangential cutter to a plotted circle
Execute a pattern intended for the adjustment of the eccentricity.
Selecting a tool.( P. 2-22)
Select cutter or roller.
Execute the eccentricity adjusting procedure.
Execute a pattern intended for the adjustment of the θ.
Execute the θ adjusting procedure.
Execute a pattern intended for the adjustment of the offset.
Execute the offset adjusting procedure.
Adjust the eccentricity.( P. 3-7,P. 3-10)
Adjust the eccentricity.( P. 3-12)
Adjust the θ angle.( P. 3-8,P. 3-11)
Adjust the θ angle.( P. 3-12)
Adjsut the offset.( P. 3-9,P. 3-11)
Adjsut the offset.( P. 3-11)
