xiv
FEATURES OF THE DEVICE
The device is capable of cutting thick materials and flexible materials
The device can cut thick materials of up to 20 mm thick by moving the cutter up and down at high speed. It
can cut a variety of materials such as sponge and fiberboard, which cannot be cut by conventional cutting plot-
ters.
Heads corresponding to materials are prepared
RT model: Pen/1.5-kg tangential cutter/reciprocal cutter
RC model: Pen/5-kg tangential cutter/reciprocal cutter
Applicable materials
Upgraded reliability and consistent cutting quality
With its four-axis ( X, Y, Z, θ ) software servo control, the device promises upgraded reliability.
With its high-rigid special drive mechanism, the device produces high- precision beautiful cutting results
while preventing overshoot and warp. Furthermore, eccentricity of the cutter holder can be adjusted through
software by the eccentricity correcting function, achieving cutting results with upgraded accuracy.
The device incorporates a mechanism that securely supports works
Air-suction work clamping system has been introduced to the table unit on which works are secured.
This allows works to be clamped without fail and to be easily placed/removed on/from the device. Further-
more, the table is equipped with a plate surface that protects the cutter blade at the time of performing die-cut.
Moreover, a set including an roll hanger is also available.
* Depending on characteristics and size of the material, it may not be possible to fix it securely.
RT Model RC Model
Sponge Corrugated fiberboard (E to AB
corrugation)
Vinyl chloride sheet for signboard Coated board No. 10
Reflecting sheet Vinyl chloride sheet for signboard
Sand-blast rubber Industrial sheet rubber
Industrial sheet rubber Pasteboard
Wood rack
Coated board No. 10
