2-2
BASIC OPERATION ON THE LOCAL MENU
LOCAL menu
Various kinds of data and functions required for the connection with your personal computer are set.
MODE SET menu
The following explains functions of the [MODE SET] in the LOCAL menu.
Function Description Reference page
TOOL SELECTION Head and tool to be used are selected.
P. 2-22
CONDITIONS Conditions for the tool selected using the [TOOL SELECTION] func-
tion are specified.
P. 2-23
TEST CUT Test cutting is performed so as to check that the settings specified using
the [CUTTING CONDITIONS] function are proper.
P. 2-29
DATA CLEAR Data received are cleared when aborting the cutting (plotting) or in
prior to the execution of the [COPY] function.
P. 2-40
ORGkey to SC.CLR Clear the mark scale correction.
P. 5-16
COPY Cutting is performed again in accordance with the data that have been
once received.
P. 4-4
VIEW Moves the head to the top right head retracting position or bottom right
and cap station.
P. 2-7
INTERFACE Communication conditions for the serial port that matches the personal
computer to be used are established.
P. 1-19
MODE TEST Settings required to match the device to the personal computer or appli-
cation functions are specified.
P. 2-2
SELF TEST
Cutting is performed in accordance with sample data so as to check the
cutting quality or whether the device itself has failed. In addition, data
are plotted using ASCII code or set values (parameters) for this device
are plotted as as to check for abnormal data.
P. 6-2
CUT AREA Size of a work attached on the device or an area for cutting is specified.
P. 4-13
AXIS ALIGN If ruled lines such as scales are printed, mechanical axes (X-axis, Y-
axis) of the device are aligned to them.
P. 2-11
TOOL ADJUST Tools and relation between tools are adjusted. Adjust Light pointer
position is adjusted.
P. 3-6
Function Description Reference page
COMMAND Commands are set to the MGL-IIc3. Switching commands on the plot-
ter side is not possible. (For the CF2, only MGL-IIC3 is available)
P. 1-24
UNIT The unit to be used when indicating numerics on the LCD is specified.
P. 4-11
AUTO VIEW A period of time from the completion of cutting (plotting) to the start of
head retraction is specified.
If a time is specified, the blower automatically switches off following
head retraction.
P. 1-25
ONE STROKE To eliminate a portion that remains uncut, unnecessary vertical motion
of the cutter is omitted to permit single-stroke cutting.
P. 4-8
GDP Resolution is adjusted to the one supported by your CAD.
P. 1-24
To Next Page
