MIMAKI CF2 Series User Manual

2-22
SELECTING A TOOL [TOOL SELECT]
Now, select a head and a tool to be used in the cases described below.
• In the case where the pen number cannot be specified on the CAD.
• In the case where [TEST CUT] function or [SELF TEST] function is executed on the device itself
• In the case where the [CMD SW] is set to “invalid” in the OPERATION mode
Tools that can be separetely set for each head are as follows:
The following describes how to set the head from A to B and the tool to cutter 2.
1. Press the key several times until the LCD indicates
page 3 of the LOCAL MENU.
2. Select the [TOOL SELECT].
3. Select the head to be used in the operation.
Every time the key is pressed, the selected head will change.
A, B, C
Heads that can be selected differ with the head models.
4. Select the tool to be used.
RecCutter 1
RecCutter 2
5. Enter the input values.
Press the key to enter the input values.
If you do not enter the input data, press the key.
Head A B C
Tool Pen / Swivel blade Reciprocal
Cutters 1 to 2
Rollers 1 to 4 /
R. cutters 1 to 2
Cutters 1 to 2
RC
head model
○○○―
RT
head model
○○―○
[LOCAL］ １ ／ ４
TOOL SELECT ――― ＞
CONDITION ――― ＞
TEST CUT ――― ＞
[LOCAL］ １ ／ ４
TOOL SELECT ――― ＞
CONDITION ――― ＞
TEST CUT ――― ＞
< TOOL SELECT > １ ／ １
HEAD ∗ A >
TOOL ∗ PEN >
< TOOL SELECT > １ ／ １
HEAD B >
TOOL RecCutter 1 >
< TOOL SELECT > １ ／ １
HEAD B >
TOOL RecCutter 1 >
[LOCAL］ １ ／ ４
TOOL SELECT ――― ＞
CONDITION ――― ＞
TEST CUT ――― ＞
