MIMAKI CF2 Series User Manual

CONFIRMATION OF CUTTING QUALITY ONLY BY THE SINGLE UNIT OF THE DEVICE [SELF
6-3
Cutting quality * / Sample *** / Circle cutting R = ***
The following describes how to execute the self-test functions.
When executing the cutting quality test and the sample test, the pen number assigning function will be rendered effec-
tive. It is necessary, therefore, to set the related values to the initial ones.
1. Establish an origin at a location where the self-test is to be performed. P. 2-39)
2. Invoke the 3rd page of the LOCAL menu on the screen.
3. Select the [SELF TEST].
Pen No. RC model RT model
1
Head
BB
Tool
Reciprocal cutter 1 Reciprocal cutter 1
2
Head
CC
Tool
Roller 1 R Cutter 1
3
Head
BB
Tool
Reciprocal cutter 2 Cutter 2
4
Head
CC
Tool
Roller 1 Cutter 2
5
Head
AA
Tool
Swievel cutter Swievel cutter
6
Head
AA
Tool
Pen Pen
[LOCAL］ １ ／ ４
TOOL SELECT ――― ＞
CONDITION ――― ＞
TEST CUT ――― ＞
［LOCAL］ ３ ／ ４
INTERFACE ――― ＞
MODE SET ――― ＞
SELF TEST ――― ＞
