V Series Operating Instructions 26 - 5
System Setup System Dialog
4. Select from the available choices in the list box. listed
NOTE: The default selections are NIBP Start/Stop, NIBP Stat, Zero All IBP,
View All ECG, Lead/Size, and Standby.
NOTE: The NIBP Start/Stop and NIBP Stat keys only display in the Navigation
Area provided NIBP or NIBP List is configured to display in the Display
Setup configuration.
NOTE: The order of the keys shown in the Quick Function row of the
Navigation Area is dependent on how the keys are ordered in the Quick
Function Keys dialog list box. For example, in FIGURE 26-2, the NIBP
Start/Stop key is listed first and displays as the first button in the Quick
Functions row.
5. Use the buttons described in TABLE 26-2 to navigate in this dialog.
6. Select the Cancel or Accept button.
•The Cancel button closes the dialog without saving the settings.
•The Accept button saves the settings and closes the dialog.
26.2.4 Configuring the Alarms Tab
Select the Alarms tab to configure the alarm silencing, lethal alarms, alarm delays, and other alarm
related settings. Except for the Lethal Alarms, which apply to Adult and Pediatric patient sizes only,
the other alarm settings apply to all patient sizes.
To configure the Alarms tab:
1. Select the Setup tab from the Navigation Area.
2. Select the System button, enter the password, then select the Accept button.
3. Select the Alarms tab.
The Alarms tab displays (as shown in FIGURE 26-3).
TABLE 26-2
BUTTON DESCRIPTION
Add Adds the selected choice to the Selected list (located to the right of the
navigation buttons).
Remove Removes the selected choice from the Selected list.
Remove All Removes all the choices from the Selected list and moves them back to
the Choices list (located to the left of the navigation buttons).
Move to Top Moves the highlighted choice to the top position in the Selected list.
Move Up Moves the highlighted choice in the Selected list up one position.
Move Down Moves the highlighted choice from the Selected list down one position.
Move to Bottom Moves the highlighted choice to the bottom position in the Selected
list.
