V Series Operating Instructions 26 - 17
System Setup System Dialog
FIGURE 26-10 Example ECG Management Setup
1. Select the Setup tab from the Navigation Area.
2. Select the System button, enter the password, then select the Accept button.
3. Select the Network tab, then select the ECG Management button (as shown in FIGURE 26-10).
4. Select the buttons described in TABLE 26-10 to configure the tab.
TABLE 26-10
BUTTON DESCRIPTION / COMMENTS CHOICES*
ECG Management
Interface
Provides ECG Management Interface choices. Off
On
File Path Select to enter a specified file path to export
the 12 Lead Interpretation in an XML format.
None
Network User Name Select to enter or change the network user
name.
Factory default is a blank value.
None
Network Password Select to enter or change the network
password.
Factory default is a blank value.
None
* The factory default configuration settings are in bold.
