- Recalibrate: Maximum capacity with weight unit, scale interval, dead load, calibration
weight, see Chapter 4.7.8.3.4.1.
- Perform a corner correction if necessary; see Chapter 4.7.8.3.7
Note:
For further information about calibrating weighing points, see Chapter 4.7.1.
Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Calib] .
WP-D
Max -------?? d= -------??
scale not ready
Weighing points @admin
Weighing point A
Weighing point B
Weighing point C
Weighing point D
Internal weighing point
Internal weighing point
xBPI scale
Pendeo Process
Parameters Calib Units
4.7.8.3.1 Quick install with search load cells and set dead load
In this menu item (under Calib), quick install with search and setting of the dead load is
performed for the digital precision pressure load cell Pendeo
®
Process.
Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Calib] - [Quick install with search load cells and set dead load] .
In this case: Select [Weighing point A] with [Pendeo Process] and press the [Calib]
soft key.
WP-D
Max -------?? d= -------??
scale not ready
Weighing points @admin
Setup Pendeo
Quick install with search load cells and set dead load
Search for connected load cells
View and assign load cells
Calibrate the scale
Assign load cell name
Service function for load cells
The Pendeo setup menu opens.
1. Unload the scale.
