Minebea Intec X3 Process Indicator PR 5410 User Manual

- In the menu [Weighing point A] - [xBPI-Scale] - [Setup] at [Conguration] -
[Weighing parameters] - [Conrming adjust.] was set to "manual".
- The communication between the device and platform is active.
Procedure:
1. Select -[Weighing point]- [xBPI-Scale] and conrm.
2. Press the [Setup] softkey.
The parameters of the xBPI-scale are read into the device.
3. Select [Calibration]- [Adjust with user weight] and conrm.
An input window appears. The previously stored user weight is displayed.
4. Change the weight value if necessary using the keyboard and conrm.
The calibration process is carried out without a weight. The calibration status is
displayed.
5. Place the weight on the scale.
The deviation is displayed in the last line with increased resolution (10-fold).
6. Press the [Accept] softkey.
The weight is displayed in high-resolution (10x).
The data are saved and the instrument returns the following message:
7. Remove the weight.
8. Press the softkey to exit the menu and to save the settings.
7 Commissioning X3 Process Indicator PR 5410
EN-189 Minebea Intec
