Sequence of [net lling] with lling signals "coarse/ne"
①
Taring:
The current gross weight is saved as the ta-
re and the net weight starts at zero.
②
Coarse:
A coarse ow (coarse and ne) is batched
until the preset value is reached.
③
Fine:
A ne ow is batched until the switch-o
point (overshoot) is reached.
④
Calming:
Time to wait during which the overshoot is
eective and scale vibrations may settle.
⑤
Tolerance checking:
The weight is determined and checked
against the tolerance values.
8.4.1.2 Net decrease (B4)
The scale is automatically discharged up to the specied value. The other parameters and
the process correspond to the [Net lling] mode; see Chapter 8.4.1.1.
Net = gross - tare
Tare = gross
X3 Process Indicator PR 5410 8 Production
Minebea Intec EN-256
