0000 1000 in byte 1
12.3.4.2 Filling control
12.3.4.2.1 Pausing lling
Requirements:
The system is lling, i.e.,
- the Dosing_Run bit is active
and
- the hold bit is not active
Example:
Set stop bit with 0100 0000 in byte 1.
Filling stops with the rising edge and the system goes to the hold status (hold state).
If the system is in hold state, lling can be restarted or canceled.
12.3.4.2.2 Restarting lling
Requirements:
The system stops, i.e., the Hold_state bit is active.
Example:
Set stop bit with 0010 0000 in byte 1.
Filling starts again with the rising edge and the system leaves the hold status (hold state)
and continues lling.
12.3.4.2.3 Canceling lling
Requirements:
The system stops, i.e., the Hold_state bit is active.
Example:
Set cancel bit with 0001 0000 in byte 1.
Filling starts again with the rising edge and the system leaves the hold status (hold state)
and goes back to the ready status (ready/idle).
12.3.4.3 Filling report
The lling results are stored after lling and only overwritten when there is a new result.
12.3.4.4 Filling error
Last_Error
The last error number is retained until it is reset.
The possible error numbers are listed in Chapter 16.6.2.
12.3.4.5 Reading the material table
The material parameters can be read from the material table of the device (PR 5410).
Procedure:
1. Write the material ID to byte 3.
2. Write command 1 to byte 0 in order to see the material parameters on the read side.
3. Write command 0000 0001 to byte 2 in order to copy the material parameters from
the material table.
12 Fieldbus interface X3 Process Indicator PR 5410
EN-307 Minebea Intec
