SPM address Data type R/W Function
B22 BYTE R Major part of version number (1.0)
B23 BYTE R Minor part of version number (1.0)
D6 UDINT R Serial number (board number)
W14 INT R Counter will be increased for every measured value.
D8 DINT R Current gross weight
D9 DINT R Current net weight
D10 DINT R Current tare weight
D11 DINT R Current gross/net weight selected with X72
D14 DINT R Max weight (FSD)
D15 DINT R Min weight
D16 DINT R Report: Gross weight
D17 DINT R Report: Net weight
D18 DINT R Report: Tare weight
D19 DINT R Report: Sequence number
D20 DINT R Application-independent: Flow value (weight change•100/minute)
if no BCD card is installed.
Standard only: BCD value for "transparent" mode
D21 DINT R Report: Date
D22 DINT R Report: Time, BCD display
D23 DINT R Activity counter, test of communication with device
D24 DINT R Standard only: Limit: Limit 1 on
D25 DINT R Standard only: Limit: Limit 1 o
D26 DINT R Standard only: Limit: Limit 2 on
D27 DINT R Standard only: Limit: Limit 2 o
D28 DINT R Standard only: Limit: Limit 3 on
D29 DINT R Standard only: Limit: Limit 3 o
D30 UDINT R/W Standard only: Analog output for "transparent" mode
D31 DINT R/W Write the value in the xed tare memory.
B144
X1152
X1153
X1154
X1155
BYTE
BOOL
BOOL
BOOL
BOOL
R
R
R
R
R
EasyFill only: Batching status 1
Batching mode active
Batching mode ready/idle
Batching mode error
Batching mode in setup
13 SPM X3 Process Indicator PR 5410
EN-317 Minebea Intec
