Minebea Intec X3 Process Indicator PR 5410 User Manual

SPM address Data type R/W Function
B145
X1160
X1161
X1162
X1163
X1164
X1165
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
R
R
R
R
R
R
R
EasyFill: Batching status 2
Batching in progress
Batching stopped
Coarse ow
Fine ow
Calming
Tolerance alarm
B146
X1168
X1169
X1170
X1171
X1172
X1173
X1174
X1175
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
W
W
W
W
W
W
W
W
W
EasyFill only: Batching command 1
Start batching with the current record:
Start/Restart
Stop/Cancel
Load a dened material and start in one step:
Start ID 1
Start ID 2
Start ID 3
Start ID 4
Start ID 5
Start ID 6
B147
X1176
X1177
X1178
X1179
X1180
X1181
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
W
W
W
W
W
W
W
EasyFill only: Batching command 2
Start ID 7
Start ID 8
Start ID 9
Start ID 10
Print report
Reset error status D67 = 0
B148
X1182
X1183
BYTE
BOOL
BOOL
W
W
W
EasyFill only: Batching command 3
Load selected material
Save selected material
B149 BYTE R/W EasyFill only: Batching modes (1 = B1; 2 = B4)
W76 DINT R/W EasyFill only: Material ID
B156–173 BYTE R/W EasyFill only: Material name for ID1–10
D44 DINT R/W EasyFill only: Set point
D45 DINT R/W EasyFill only: Preset
D46 DINT R/W EasyFill only: Material overshoot (OVS)
D47 DINT R/W EasyFill only: Calming time [ms]
D48 DINT R/W EasyFill only: Tolerance below set point
D49 DINT R/W EasyFill only: Tolerance above set point
W104 (B208) WORD R EasyFill only: Report: Material ID
B212–229 BYTE R EasyFill only: Report: Material name
D58 DINT R EasyFill only: Report: Batched weight
D59 DINT R EasyFill only: Report: Set point
X3 Process Indicator PR 5410 13 SPM
Minebea Intec EN-318
