No. Description
1 Slot 4: Slot for eldbus card
2 Slot 1: Slot for serial interface card
3 Slot 2: Slot for serial interface card
4 Power supply (under the cover)
5 Lithium battery (under the cover for the power supply)
6 Digital inputs and outputs
7 CAL switch
8 Ethernet port
9 RS-232 serial interface
10 Display board
11 Load cell connection
12 Solder bridge
4 Device installation X3 Process Indicator PR 5410
EN-33 Minebea Intec
