Minebea Intec X3 Process Indicator PR 5410 User Manual

Conguration PR 5410 Printer conguration
- [Serial ports parameters]- [Printer]- [Built-
in RS-232]- [Param]:
- [Protocol] to "RTS/CTS"
- [Baudrate] to "9600"
- [Bits] to "8"
- [Parity] to "none"
- [Stop bits] to "1"
- [Output mode] to "Raw"
The printer must be set to "Line Mode" (the fac-
tory setting is Page Mode). Press the "FEED" key
to switch from one to the other.
The procedure can be found in the printer opera-
ting instructions.
4.4.4.3 Connecting an IS platform
One IS platform scale with xBPI or SBI protocol can be connected via the internal RS-232
interface or the PR 5510/02 card or the PR 5510/04 card.
Conguration PR 5410
- [Serial ports parameters]- [xBPI port]- [Built-in RS-232]
X3 Process Indicator PR 5410 4 Device installation
Minebea Intec EN-38
