8 Operation
Maschinenfabrik Reinhausen GmbH 2020 1973587317/21 EN TAPCON
®
Parameters Master/Client
CAN bus address 1...16
Circuit breaker configuration User-defined
1)
Table69: Configuring the topology
1)
If you configure all switches with node 0 on a device, that device does not
send any topology information over the CAN bus and operates solely as a
topology client.
8.18.5.3 Configuring the topology
To configure the topology, you must adjust the following settings:
▪ Prim/sec. topology
▪ CAN address 1(2)...16 device name
▪ CAN bus address
▪ Circuit breaker configuration
Prim/sec. topology You can use this parameter to set the condition that defines when the trans-
formers are connected in parallel. You can select the following options:
▪ Secondary side: Transformers are considered to be connected in parallel
when the circuit breakers on the secondary side of the transformers are
closed.
▪ Both sides: Transformers are considered to be connected in parallel when
the circuit breakers on the primary and secondary sides of the transform-
ers are closed.
▪ At least one side: Transformers are considered to be connected in parallel
when the circuit breakers on the primary or secondary side of the trans-
formers are closed.
To set the condition, proceed as follows:
1. Go to Settings > Parameters > Parallel operation > Prim/sec topology.
2. Select the desired option.
3. Press the Accept button to save the modified parameter.
CAN address 1(2)...16
device name
You can use these parameters to set the name of the transformers. The de-
vice uses the name in the information display for the topology.
To set the transformer name, proceed as follows:
1. Go to Settings > Parameters > Parallel operation > CAN address
1(2)...16 device name.
2. Enter the desired name.
3. Press the Accept button to save the modified parameter.
CAN bus address Set the CAN bus address. Observe the information provided in the Assigning
CAN bus address [►Page 189] section.
