14 Overview of parameters
Maschinenfabrik Reinhausen GmbH 2020304 3587317/21 ENTAPCON
®
Parameter Setting range Factory setting Current setting
U> relative/absolute Relative, Absolute Relative
U> [V] 100.0...160.0 V 110.0 V
U> [%] 100.0...140.0% 110.0%
U> hysteresis 0.0...10.0 V 0.0 V
U> delay time 0.5...60.0 s 0.5s
U> behavior Off, High-speed return U-,
Auto blocking, Auto/man-
ual blocking
Off
U>> relative/absolute Relative, Absolute Relative
U>> [V] 100.0...160.0 V 120.0 V
U>> [%] 100.0...140.0% 120.0%
U>> hysteresis 0.0...10.0 V 0.0 V
U>> delay time 0.5...60.0 s 0.5s
U>> behavior Off, High-speed return U-,
Auto blocking, Auto/man-
ual blocking
Off
Settings > Parameter > Current monitoring
I< relative/absolute Relative, Absolute Relative
I< [A] 0.00...12.50 A 0.00 A
I< [%] 0.0...250.0% 0.0%
I< hysteresis 0.00...12.50 A 0.00 A
I< delay time 0.0...60.0 s 0.0 s
I< behavior Off, Auto blocking, Auto/
manual blocking
Off
I<< relative/absolute Relative, Absolute Relative
I<< [A] 0.00...12.50 A 0.00 A
I<< [%] 0.0...250.0% 0.0%
I<< hysteresis 0.00...12.50 A 0.00 A
I<< delay time 0.0...60.0 s 0.0 s
I<< behavior Off, Auto blocking, Auto/
manual blocking
Off
I> relative/absolute Relative, Absolute Relative
I> [A] 0.00...12.50 A 10.00 A
I> [%] 50.0...250.0% 110.0%
I> hysteresis 0.00...12.50 A 0.00 A
I> delay time 0.0...60.0 s 0.0 s
I> behavior Off, Auto blocking, Auto/
manual blocking
Off
I>> relative/absolute Relative, Absolute Relative
