14 Overview of parameters
Maschinenfabrik Reinhausen GmbH 2020 3053587317/21 EN TAPCON
®
Parameter Setting range Factory setting Current setting
I>> [A] 0.00...12.50 A 10.00 A
I>> [%] 50.0...250.0% 110.0%
I>> hysteresis 0.00...12.50 A 0.00 A
I>> delay time 0.0...60.0 s 0.0 s
I>> behavior Off, Auto blocking, Auto/
manual blocking
Off
Settings > Parameters > Power monitoring
S< [MVA] 0.0...1,000.0 MVA 0.0 MVA
S< hysteresis 0.0...100.0 MVA 0.1 MVA
S< delay time 0.0...60.0 s 5.0 s
S<< [MVA] 0.0...1,000.0 MVA 0.0 MVA
S<< hysteresis 0.0...100.0 MVA 0.1 MVA
S<< delay time 0.0...60.0 s 5.0 s
S> [MVA] 0.0...1,000.0 MVA 10.0 MVA
S> hysteresis 0.0...100.0 MVA 0.1 MVA
S> delay time 0.0...60.0 s 5.0 s
S>> [MVA] 0.0...1,000.0 MVA 10.0 MVA
S>> hysteresis 0.0...100.0 MVA 0.1 MVA
S>> delay time 0.0...60.0 s 5.0 s
P< [MW] -1,000.0...1,000.0 MW 0.0 MW
P< hysteresis 0.0...100.0 MW 0.1 MW
P< delay time 0.0...60.0 s 5.0 s
P<< [MW] -1,000.0...1,000.0 MW 10.0 MW
P<< hysteresis 0.0...100.0 MW 0.1 MW
P<< delay time 0.0...60.0 s 5.0 s
P> [MW] -1,000.0...1,000.0 MW 0.0 MW
P> hysteresis 0.0...100.0 MW 0.1 MW
P> delay time 0.0...60.0 s 5.0 s
P>> [MW] -1,000.0...1,000.0 MW 0.0 MW
P>> hysteresis 0.0...100.0 MW 0.1 MW
P>> delay time 0.0...60.0 s 5.0 s
Q< [kVar] -100,000...100,000 kVar 0 kVar
Q< hysteresis 0...10,000 kVar 1,000 kVar
Q< delay time 0.0...60.0 s 5.0 s
Q<< [kVar] -100,000...100,000 kVar 0 kVar
