14 Overview of parameters
Maschinenfabrik Reinhausen GmbH 2020306 3587317/21 ENTAPCON
®
Parameter Setting range Factory setting Current setting
Q<< hysteresis 0...10,000 kVar 1,000 kVar
Q<< delay time 0.0...60.0 s 5.0 s
Q> [kVar] -100,000...100,000 kVar 10,000 kVar
Q> hysteresis 0...10,000 kVar 1,000 kVar
Q> delay time 0.0...60.0 s 5.0 s
Q>> [kVar] -100,000...100,000 kVar 10,000 kVar
Q>> hysteresis 0...10,000 kVar 1,000 kVar
Q>> delay time 0.0...60.0 s 5.0 s
cos φ < 0.00...1.00 0.85
cos φ < hysteresis 0.00...0.10 0.01
cos φ < delay time 0.0...60.0 s 5.0 s
cos φ << 0.00...1.00 0.80
cos φ << hysteresis 0.00...0.10 0.01
cos φ << delay time 0.0...60.0 s 5.0 s
Settings > Parameters > Reversal of power flow
Reversal of power flow hysteresis 0.0...100.0 MW 0.1 MW
Reversal of power flow delay time 0.0...60.0 s 5.0 s
Behavior for reversal of power
flow
Off, Target-tap-position
operation, Auto blocking,
Auto/manual blocking
Off
Settings > Parameters > Tap position monitoring
Pos < -128...128 0
Pos < delay time 0.0...60.0 s 0.0 s
Pos < behavior Off, Auto blocking posi-
tion-, Auto/manual block-
ing position-
Off
Pos > -128...128 0
Pos > delay time 0.0...60.0 s 0.0 s
Pos > behavior Off, Auto blocking position
+, Auto/manual blocking
position+
Off
Settings > Parameters > Bandwidth monitoring
Function monitoring Off, Auto, Auto/manual Off
Hysteresis for function monitoring 0.00...1.00% 0.00%
Function monitoring delay time 1...60 min 15min
Hysteresis for lower bandwidth 0.00...1.00% 0.00%
Lower bandwidth delay time 0.0...60.0 s 0.0 s
Hysteresis for upper bandwidth 0.00...1.00% 0.00%
