14 Overview of parameters
Maschinenfabrik Reinhausen GmbH 2020 3073587317/21 EN TAPCON
®
Parameter Setting range Factory setting Current setting
Upper bandwidth delay time 0.0...60.0 s 0.0 s
Settings > Parameters > Switching interval monitoring (Total, Raise, Lower)
Maximum number of total tap-
change operations
1...100 10
Time period for total tap-change
operations
1...1,440 min 5min
Message duration for total tap-
change operations
1...60 min 15min
Behavior for total tap-change op-
erations
Off, Auto blocking, Auto-
>Manual
Off
Maximum number of raise opera-
tions
1...100 10
Time period of raise operations 1...1,440 min 5min
Message duration for raise oper-
ations
1...60 min 15min
Behavior for raise operations Off, Auto blocking position
+, Auto->Manual
Off
Maximum number of lower opera-
tions
1...100 10
Time period for lower operations 1...1,440 min 5min
Message duration for lower oper-
ations
1...60 min 15min
Behavior for lower operations Off, Auto blocking posi-
tion-, Auto->Manual
Off
Settings > Parameters > Move to the defined target tap position
Target-tap-position operation -128...128 0
Settings > Parameters > Analog tap position capture (optional)
Upper tap position -128..128 In accordance with order
Lower tap position -128..128 In accordance with order
Settings > Parameters > IEC 61850 (optional)
IP address
2
0.0.0.0...255.255.255.255 192.168.10.254
Subnet mask
2
0.0.0.0...255.255.255.255 255.255.255.0
Gateway address
2
0.0.0.0...255.255.255.255 0.0.0.0
IED name
2
- TAPCON
Device ID
2
- TAPCON
Access point - -
Edition Edition 1; Edition 2 Edition 1
Settings > Parameters > IEC 60870-5-101 (optional)
Serial interface
2
RS232, RS485 RS232
Baud rate
2
9.6...115.2 kilobaud 9.6 kilobaud
