14 Overview of parameters
Maschinenfabrik Reinhausen GmbH 2020308 3587317/21 ENTAPCON
®
Parameter Setting range Factory setting Current setting
Transmission procedure
2
Unbalanced, Balanced Unbalanced
Octet number of link address
2
0...2 1
Link address
2
0...65,535 1
Octet number of ASDU address
2
0...2 1
ASDU address
2
0...65,535 1
Octet number of information ob-
ject address
2
0...3 1
Octet number of cause of trans-
mission
2
0...2 1
Number of databits
2
5...8 8
Parity
2
None, Even, Odd Even
Number of stop bits
2
1...2 1
Settings > Parameters > IEC 60870-5-103 (optional)
Serial interface
2
RS232, RS485 RS232
Baud rate
2
9.6...115.2 kilobaud 9.6 kB
ASDU address
2
0...255 1
Number of databits
2
5...8 8
Parity
2
None, Even, Odd Even
Number of stop bits
2
1...2 1
Settings > Parameters > IEC 60870-5-104 (optional)
IP address
2
0.0.0.0...255.255.255.255 192.168.10.254
Subnet mask
2
0.0.0.0...255.255.255.255 255.255.255.0
Gateway address
2
0.0.0.0...255.255.255.255 0.0.0.0
TCP port
2
0...65,535 2,404
ASDU address
2
0...65,535 1
Settings > Parameters > Modbus (optional)
Transmission format
2
RTU, TCP, ASCII In accordance with order
Modbus address
2
1...247 1
IP address
2
0.0.0.0...255.255.255.255 192.168.10.254
TCP port
2
0...65,535 502
Maximum TCP connections
2
0...100 10
TCP Keepalive
2
Off, On Off
Serial interface
2
RS232, RS485 In accordance with order
Baud rate
2
9.6...115.2 kilobaud 9.6 kilobaud
Number of databits
2
5...8 In accordance with order
Parity
2
None, Even, Odd In accordance with order
Number of stop bits
2
1...2 In accordance with order
