Cassette sensor list:
Name Status Name Status
CAS1
(
OPEN)
Casette 1 open/closed
OFF: Closed
ON: Open
PES1
(PES)
Paper empty sensor for cassette 1
OFF: No paper
ON: Paper detected
SIDE_OP
(JAMC)
Interlock sensor (side cover open/
closed)
OFF: Closed
ON: Open
CAS2
(OPEN OP)
Casette 2 open/closed
OFF: Closed
ON: Open
PES2
(PES OP)
Paper empty sensor for cassette 2
OFF: No paper
ON: Paper detected
JAM2_OP
(JAMC2)
Cassette 2 side cover open/closed
OFF: Closed
ON: Open
CAS3
(OPEN OP)
Casette 3 open/closed
OFF: Closed
ON: Open
PES3
(PES OP)
Paper empty sensor for cassette 3
OFF: No paper
ON: Paper detected
JAM3_OP
(JAMC2)
Cassette 3 side cover open/closed
OFF: Closed
ON: Open
CAS4
(OPEN OP)
Casette 4 open/closed
OFF: Closed
ON: Open
PES4
(PES OP)
Paper empty sensor for cassette 4
OFF: No paper
ON: Paper detected
JAM4_OP
(JAMC2)
Cassette 4 side cover open/closed
OFF: Closed
ON: Open
PESM
(TRAYS)
Paper empty sensor for bypass tray
OFF: No paper
ON: Paper detected
FRNT_OP
(FCOVER)
Front cover open/closed
OFF: Closed
ON: Open
CSST2 Cassette 2 sensor
OFF: No unit
ON: Unit detected
CSST3 Cassette 3 sensor
OFF: No unit
ON: Unit detected
CSST4 Cassette 4 sensor
OFF: No unit
ON: Unit detected
Sensor for cassette 2 to 4 are displayed only when they are installed to the machine.
