5-22
PLATE PRINTER B
1. Remove one screw [1] (jointed with ground wire) and remove the PLATE PRINTER B [2].
2. Disconnect one connector [3].
>

@
>

@
>

@
Important
When attaching the Plate printer B, be careful not to pinch the harness.
