Muratec MFX-3595 User Manual

5-59
PRINTER HEAD
1. Open the Cover front and remove the consumable supply.
2. Remove the Printer fuser. (See “PRINTER FUSER” on page 5-58.)
3. Remove one screw [1], then remove the Holder LPH B [2].
4. Release the PRINTER HEAD [3] lock by pressing in and pull out the FFC LPH [5].
[
1
]
[
2
]
[
3
]
[
5
]
[
4
]
