3-119
3.32.2 Capturing packet data from machine control panel
When you capture packets using USB memory device, a file named “tcpdump.cap” will be created on the
root. If there already exists a file with the same file name, that file will be overwritten with the new data.
1. Connect a USB memory to the machine.
2. Press <Mode>, <*>, <5>, <8>.
3. Press [Capture], and then [Yes].
4. To stop capturing, press [Stop] and then [Yes].
CAUTION
Disconnect the USB memory device after capturing has finished.
3.33 Storage maintenance
The storage on the OfficeBridge is an SD card. The following operations are available with this function:
Storage Export : Export the machine data to a storage device.
Disable SD Storage : Permanently disables the SD card from being read to prevent data from being ac-
cessed when the unit is disposed.
3.33.1 Storage export
Important
Use this feature in following cases:
• To replace the SD card from a standard card to an optional card
• When the SD card has become not-write-able.
Do not perform this feature when you replace the main control board. In such care, refer to page 5-36.
1. Insert the new SD card to a card reader, and connect the card reader to the machine.
2. Press <Mode>, <*>, <5>, <9>.
3. Press [Storage Export].
4. Press [Yes].
To Next Page
