5-78
Assembling the ASSY SCRAPER
1. Attach the Spring T scraper [1] by passing through the Scraper hole [2].
[
1
]
[
2
]
2. Install the Scraper [2] to the Holder scraper [3].
3. Install two Rollers star [4] to the Holder scraper [3].
[
3
]
[
4
]
[
2
]
[
4
]
