Muratec MFX-3595 User Manual

5-83
STAPLER (MFX-3595)
1. Remove the Cover left. (See “PCB PSU” on page 5-40.)
2. Remove the ASSY STAPLER. (See “ASSY STAPLER (MFX-3595)” on page 5-81.)
3. Remove the Assy stapler interlock-cable. (See “ASSY STAPLER INTERLOCK-CABLE (MFX-3595)” on
page 5-82.)
4. Remove three screws [1], then remove the STAPLER [2].
[
1
]
[
1
]
[
1
]
[
2
]
