Muratec MFX-3595 User Manual

5-61
8. Remove five screws [5], and gently suspend the Stay top R [6].
(Use caution not to damage the harness on the Chassis drive side.)
9. Pull out the ASSY INTERLOCKSW-CBL [7] upwards.
10. Disconnect the junction connector [8].
[
5
]
[
5
]
[
5
]
[
5
]
[
5
]
[
6
]
[
7
]
[
8
]
