Virtual Private Networking Using IPSec Connections
253
ProSecure Unified Threat Management (UTM) Appliance
Figure 145.
2. Select the radio buttons and complete the fields and as explained in the following table:
Table 58. IPSec VPN Wizard settings for a gateway-to-gateway tunnel
Setting Description
About VPN Wizard
This VPN tunnel will connect
to the following peers
Select the Gateway radio button. The local WAN port’s IP address or
Internet name displays in the End Point Information section of the screen.
Connection Name and Remote IP Type
What is the new Connection
Name?
Enter a descriptive name for the connection. This name is used to help you
to manage the VPN settings; the name is not supplied to the remote VPN
endpoint.
What is the pre-shared key? Enter a pre-shared key. The key needs to be entered both here and on the
remote VPN gateway. This key needs to have a minimum length of
8 characters and should not exceed 49 characters.
This VPN tunnel will use
following local WAN Interface
(multiple WAN port models
only)
Select a WAN interface from the drop-down list to specify which local WAN
interface the VPN tunnel uses as the local endpoint.
Select the Enable RollOver? check box to enable VPN rollover, and then
select a WAN interface from the drop-down list to the right of the check box
to specify the interface to which the VPN rollover should occur.
Note: If the multiple WAN port model is configured to function in WAN
auto-rollover mode, you can use the VPN Wizard to configure VPN rollover
and do not need to configure this manually.
