Introduction
29
ProSecure Unified Threat Management (UTM) Appliance
LED Descriptions, UTM9S and Modules
The following table describes the function of each LED on the UTM9S and the modules.
LAN ports
Left LED Off The LAN port has no link.
On (green) The LAN port has detected a link with a connected Ethernet device.
Blinking (green) Data is being transmitted or received by the LAN port.
Right LED Off The LAN port is operating at 10 Mbps.
On (amber) The LAN port is operating at 100 Mbps.
On (green) The LAN port is operating at 1000 Mbps.
DMZ LED Off Port 4 (UTM5, UTM9S, UTM10, UTM25, and UTM150) or port 6 (UTM50) is
operating as a normal LAN port.
On (green) Port 4 (UTM5, UTM9S, UTM10, UTM25, and UTM150) or port 6 (UTM50) is
operating as a dedicated hardware DMZ port.
WAN ports
Left LED Off The WAN port has no physical link, that is, no Ethernet cable is plugged into
the UTM.
On (green) The WAN port has a valid connection with a device that provides an Internet
connection.
Blinking (green) Data is being transmitted or received by the WAN port.
Right LED Off The WAN port is operating at 10 Mbps.
On (amber) The WAN port is operating at 100 Mbps.
On (green) The WAN port is operating at 1000 Mbps.
Active LED
(multiple
WAN port
models only)
Off The WAN port either is not enabled or has no link to the Internet.
On (green) The WAN port has a valid Internet connection.
Table 3. LED descriptions UTM9S
LED Activity Description
Power LED On (green) Power is supplied to the UTM.
Off Power is not supplied to the UTM.
Table 2. LED descriptions UTM5, UTM10, UTM25, UTM50, and UTM150 (continued)
LED Activity Description
