Virtual Private Networking Using IPSec Connections
318
ProSecure Unified Threat Management (UTM) Appliance
View the Active L2TP Users
 To view the active L2TP tunnel users:
Select Monitoring > Active Users & VPNs > L2TP Active Users. The L2TP Active Users
screen displays:
Figure 194.
The List of L2TP Active Users table lists each active connection with the information that is
described in the following table.
The default poll interval is 5 seconds. To change the poll interval period, enter a new value in
the Poll Interval field, and then click the Set Interval button. To stop polling, click the Stop
button.
Table 82. L2TP Active Users screen information
Item Description
Username The name of the L2TP user that you have defined (see Configure User Accounts on
page 378).
Remote IP The client’s IP address on the remote LAC.
L2TP IP The IP address that is assigned by the L2TP server on the UTM.
Action This column is not applicable to L2TP.
