Virtual Private Networking Using IPSec Connections
317
ProSecure Unified Threat Management (UTM) Appliance
Figure 193.
2. Enter the settings as explained in the following table:
3. Click Apply to save your settings.
Table 81. L2TP Server screen settings
Setting Description
L2TP Server
Enable L2TP Server To enable the L2TP server, select the Enable check box. Complete the following
fields:
Start IP Address Type the first IP address of the address pool. This address
is used for distribution to the UTM.
End IP Address Type the last IP address of the address pool. A maximum of
six contiguous addresses can be part of the pool. (The first
address of the pool cannot be assigned to a user.)
User time out Enter the time-out period in seconds, from 300 to 1800
seconds. If there is no traffic from a user, the connection is
disconnected after the specified period.
Authentication
Select one or more of the following authentication methods to authenticate L2TP users:
• PAP. RADIUS-Password Authentication Protocol (PAP).
• CHAP. RADIUS-Challenge Handshake Authentication Protocol (CHAP).
• MSCHAP. RADIUS-Microsoft CHAP (MSCHAP).
• MSCHAPv2. RADIUS-Microsoft CHAP version 2 (MSCHAPv2).
Note: For each authentication method that you want to use for L2TP users, you need to have created a
domain that supports the authentication method (see Configure Domains on page 365) and have added the
L2TP users to the domain (see Configure User Accounts on page 378).
