xDSL Module for the UTM9S
519
ProSecure Unified Threat Management (UTM) Appliance
4. Configure secondary WAN addresses on the WAN port (optional). Configure aliases for
the WAN port. See Configure Secondary WAN Addresses on page 537.
5. Configure Dynamic DNS on the WAN port (optional). Configure your fully qualified
domain names during this phase (if required). See Configure Dynamic DNS on page 539.
6. Configure the WAN options (optional). Optionally, you can enable the WAN port to
respond to a ping, and you can change the factory default MTU size and port speed.
However, these are advanced features, and changing them is not usually required. See
Configure Advanced WAN Options on page 541.
Each of these tasks is detailed separately in this appendix.
Note: For information about how to configure the WAN meter, see Enable
the WAN Traffic Meter on page 434.
Configure the xDSL Settings
Before you can configure the DSL Internet connection to your ISP, you need to configure the
ADSL or VDSL settings and, if required, the ATM multiplexing method. These settings are
usually provided by your ISP, but you can autodetect these settings.
Note: Autodetecting the DSL settings takes about 25 minutes.
 To configure the xDSL settings:
1. Select Network Config > WAN Settings. The WAN screen displays (see Figure 306 on
page 521).
2. Click the Edit button in the Action column of the SLOT-x interface. The SLOT-x ISP Settings
screen displays (see Figure 307 on page 522).
3. Select the xDSL Settings option arrow. The xDLS Settings screen displays:
