NETGEAR UTM5 User Manual

Manually Configuring Internet and WAN Settings
73
ProSecure Unified Threat Management (UTM) Appliance
7. In the Internet (IP) Address section of the screen (see the following figure), configure the IP
address settings as explained in the following table. Click the Current IP Address link to
see the currently assigned IP address.
Figure 41.
Other (PPPoE)
(continued)
Connection
Reset
Select the Connection Reset check box to specify a time when the
PPPoE WAN connection is reset, that is, the connection is disconnected
momentarily and then reestablished. Then, specify the disconnect time
and delay.
Disconnect
Time
Specify the hour and minutes when the connection should
be disconnected.
Delay Specify the period in seconds after which the connection
should be reestablished.
Table 15. Internet IP address settings
Setting Description
Get Dynamically
from ISP
If your ISP has not assigned you a static IP address, select the Get Dynamically from
ISP radio button. The ISP automatically assigns an IP address to the UTM using DHCP
network protocol.
Client Identifier If your ISP requires the client identifier information to assign an
IP address using DHCP, select the Client Identifier check box.
Vendor Class Identifier If your ISP requires the vendor class identifier information to
assign an IP address using DHCP, select the Vendor Class
Identifier check box.
Use Static IP
Address
If your ISP has assigned you a fixed (static or permanent) IP address, select the Use
Static IP Address radio button, and enter the following settings:
IP Address Static IP address assigned to you. This address identifies the
UTM to your ISP.
Subnet Mask The subnet mask is usually provided by your ISP.
Gateway IP Address The IP address of the ISP’s gateway is usually provided by
your ISP.
Table 14. PPTP and PPPoE settings (continued)
Setting Description
