Oki MC860 Maintenance Manual

43967002TH Rev.1
126 /
Oki Data CONFIDENTIAL
3. Installation
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
Mail Server
Setup
POP User ID User ID It sets the log-in name that is used when
logging on the sever used for SMTP
certification or “E-mail reception print”.
POP Password Password It sets the log-in name that is used when
logging on the sever used for SMTP
certification or “E-mail reception print”.
LDAP
Server
Setting
Server
Setting
LDAP
Server
IP address
or name of
server
Sets IP address of LDAP server or sets
name of server.
Port No. 1
~
389
~
65535
Set port number of LDAP server.
Timeout 10
~
30
~
120
Set timeout value(seconds) for search
response from LDAP server.
Max.
Entries
5 entries
~
100 entries
The maximum number of the result of
search to be acquired is set.
Seach
Root
Specifies position to start searching the
LDAP directory.
Attr Name 1 Name search
condition 1
Specify attribute that is used for searching
name.
Default setup is “cn”.
Name 2 Name search
condition 2
Specify attribute that is used for searching
name.
Default setup is “cn”.
Name 3 Name search
condition 3
Specify attribute that is used for searching
name.
Default setup is “givenName”.
E-mail
Address
E-mail
address
search
condition
Specify attribute that is used for searching
E-mail address.
Default setup is “mail”.
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
LDAP
Server
Setting
Attr Addnl
Filter
Additional
setup
Specify addition attribute used for
searching.
Authentication Method Anonymous
Simple
Digest-MD5
Secure Protocol
Specify method of certification.
DNS server setup is required for Digest-
MD5
Secure protocol server setup is required
for Secure Protocol.
User ID User ID Sets the user ID for certification of the
LDAP server.
When certification of the LDAP server
setup is “Anonymous”, this menu is not
displayed.
Password Password Set certification password of LDAP server.
When certification of the LDAP server
setup is “Anonymous”, this menu is not
displayed.
Encryption None
LDAPS
STARTTLS
Set encryption of communication with
LDAP server.
Secure
PrtcSrv
Setting
Domain Domain name Set realm name for Kelperos certification.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
