4. Part Replacement
(5) Remove the eleven screws (silver)
and remove the cover plate . (6) Disconnect the two FFC connectors in the right and left, and disconnect the two
connectors
from the relay PCB (P6Y) . Remove the color regist Assy , the
five screws (silver)
and the color regist Assy .
