Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
288 /
7. Troubleshooting
Displayed message Descriptions
Checking Sectors
nnn%
Displays that a sector of HDD is being checked.
Check process of the sector is valid to start from
"Management"-"Storage Maint Setup"-Check All Sectors" of
Admin Setup Menu.
nnn: Percentage of checked capacity
Program Update Mode Displays that a unit is a special mode to conduct the update
of the NIC program (Controller firmware).
Wait a Moment
Program Data Receiving
Displays that the NIC program data to update is being
received.
This message is displayed in Program Update Mode.
If this status occurred during the unit initialinzing the message
is displayed by English.
Wait a Moment
Program Data Received OK
Displays that the NIC program data to update has been
received.
This message is displayed in Program Update Mode.
If this status occurred during the unit initialinzing the message
is displayed by English.
Check Data
Program Data Receive
Error <%DLCODE%>
An error has happened while the printer is receive-processing
the NIC download data.This message is displayed in Program
Update Mode.
%DLCODE%
1: File size error
2: Check-sum error
3: Invalid printer model number
4: Invalid module I/F version
5: Invalid FAT version
If this status occurred during the unit initialinzing the message
is displayed by English.
Wait a Moment
Program Data Writing
The unit is writing the NIC download data. This message is
displayed in Program Update Mode.
Power Off/On
Program Data Written OK
The printer finished writing the NIC download data. This
message is displayed in Program Update Mode.
Displayed message Descriptions
Check Data
Program Data Write Error
<%DLCODE%>
An error has happened while the printer is writing the NIC
download data. This message is displayed in Program Update
Mode.
%DLCODE%
1: Memory allocation error
2: Download file error
3: Device allocation error
4: No device space
5: File writing failure
6: CU-F/W mismatch
If this status occurred during the unit initialinzing the message
is displayed by English.
Inspection is required.
PU Flash Error
It is shown that PU firmware has booted in Loader mode.
If initialization is completed, it will change to the status of no. 20.
This status may occur also in a user environment. When
it occurs, the maintenance by a maintenance member is
required (equivalent to S/C).
Inspection is required.
PU Communication Error
Displays that communication to PU firmware failed.
This status may occur also in a user environment. When
it occurs, the maintenance by a maintenance member is
required (equivalent to S/C).
If this status occurred during the unit initialinzing the message
is displayed by English.
Status Mode Displays that normal Online mode starts.
Data (Job) from an external portion is processed even though
an error takes place after Online (ready) state once this mode
starts.
Displays Error or Warning on a panel.
This function is secret to users. Therefore, this status does not
occur in a user environment.
HDD Error
To HDD format
Select [Format]
To shut down
Select [Cancel]
Indicates that the unformated HDD is detected during the
initializing.
[Format] pressed, HDD format is started and the unit is
rebooted automalically.
[Cancel] pressed, the unit is shut down.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
