Page #298 background imageLoading...
Page #298 background image
Oki Data CONFIDENTIAL
43967002TH Rev. 1
298 /
7. Troubleshooting
Displayed message Descriptions
Received invalid data.
Press <Stop> key
Indicates that a job has been deleted because corruption
of data has been detected by the integrity verification in
authentication printing.
Received invalid data.
Press <Stop> key
Invalid data was received. Press the On-line switch and
eliminate the warning. Displayed when unsupported PDL
command is received or a spool command is received without
HDD.
Cannot store Fax job. Indicates that the number of delayed fax sending registration
was aleardy full.
Searching for Address
Failed
Indicates that it does not find out the target addresses from
LDAP Server.
Search Results Exceeded
the Limit.
Indicates that search results of LDAP server exceeded the
upper limit value.
%TRAY% missing. Indicates that paper trays are not installed.
%TRAY%
Tray1
Tray2
Tray3
Access limitation error
Monochrome printing was
performed due to the color
printing limitation.
Notifies users that color print jobs were printed by
monochrome because they are not permitted for color
printing. (Related to JobAccount Color Access Contorl.).
Access limitation error
Monochrome printing was
performed due to the color
printing limitation.
Notifies users that color print jobs were cancelled because
they are not permitted for color printing. (Related to
JobAccount Color Access Contorl.).
Access limitation error
Data was deleted due to
the printing limitation.
Notifies users that jobs were cancelled because they are not
permitted for printing. (Related to JobAccount Color Access
Contorl.).
Remove the connected
USB device.
Unsupported USB device
is connected.
Indicates that the unsupported USB device was connected.
This message will be displayed until the unsupported USB
device disconnected.
Displayed message Descriptions
Remove the USB Hub.
USBHub is connected.
Indicates that the unsupported USB Hub was connected.
This message will be displayed until the unsupported USB
Hub disconnected.
Accounting Log Buffer is
Near Full
It indicates the Job Accounting log buffer is near full.
Accounting Log Writing
Error
Press <Stop> key
The Job Accounting log is not registered correctly because of
thr disc access error is occurred during accounting log writing
into HDD (Related to Logging).
This message is displayed until STOP key pressed.
Job Log Writing Error
Press <Stop> key
The log is not registered correctly because of thr disc access
error is occurred during system job log writing into HDD.
This message is displayed until STOP key pressed.
Accounting Log Buffer Full
(Delete old logs)
The function isn't accepted because log buffer is full. (Related
to JobAccount).
This message is displayed, if the log buffer is full and
"Operation at Log Full" in Job Accounting Server Software is
set to "Delete old logs".
The new jobs will be able to execute after the following
operations.
1. The log in the unit must be got by Job Accounting Server
Software.
2. The setting of "Operation at Log Full" must be changed to
"Does not acquire logs".
Error
Error Code
Displayed message Descriptions
Memory Overflow.
Press <Stop> key
Display that memory overflow is occurred during PC
Fax Job receiving.
Return to Mode Selection screen by the pressing Stop
button.
Login Failed Displays that the entered PIN ID is incorrect.
Incorrect Password. Displays that the entered password is incorrect.
