Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
308 /
7. Troubleshooting
Error Code
Displayed message Descriptions
554
555
556
557
%COLOR% Toner
Regional Mismatch:
%ERRCODE%
The signature ID of toner cartridge is not proper to the
distribution channel, but the group of signature ID is
proper (OKI regional mismatch).
As probable missing to measure the amount of toner,
the printer notifies error status and stop printing.
Error 554 : Y
Error 555 : M
Error 556 : C
Error 557 : K
When this error occurs in more than one color toners,
the all tonners that have this error status and a high
most priolity error code are displayed.
Example)
•
When this error occurs in all toners:
YMCK Toner Regional Mismatch:
554
• When this error occurs in MC toners:
MC Toner Regional Mismatch:
555
560
561
562
563
Please install New
%COLOR% Image
Drum.
The toner empty error is occurred after the image drum
reached its life.
Error 560 : Y
Error 561 : M
Error 562 : C
Error 563 : K
This is displayed until a user exchanges the image
drum.
610
611
612
613
%COLOR% Toner not
installed.
The toner cartridge is not installed.
Error 610 : Y
Error 611 : M
Error 612 : C
Error 613 : K
Four following behavior is carried out by mode of
operation.
1. Only warning display. (This error is not displayed).
2. Warning status takes effect at Cover Open/Close.
3. With no automatic concentration compensation .
4. This error is displayed and it stops.
Error Code
Displayed message Descriptions
614
615
616
617
%COLOR% Toner
Regional Mismatch:
%ERRCODE%
The signature ID of toner cartridge is not proper to the
distribution channel, and the group of signature ID is
not proper (OEM channel mismatch).
Error 614 : Y
Error 615 : M
Error 616 : C
Error 617 : K
When this error occurs in more than one color toners,
the all tonners that have this error status and a high
most priolity error code are displayed.
Example)
• When this error occurs in all toners:
YMCK
Toner Regional Mismatch:
614
• When this error occurs in MC toners:
MC Toner Regional Mismatch:
615
620
621
622
623
%COLOR% Toner
Regional Mismatch:
%ERRCODE%
The signature ID of toner cartridge is not proper to the
distribution channel, and the group of signature ID is
protected (OEM mismatch).
Error 620 : Y
Error 621 : M
Error 622 : C
Error 623 : K
When this error occurs in more than one color toners,
the all tonners that have this error status and a high
most priolity error code are displayed.
Example)
• When this error occurs in all toners:
YMCK Toner Regional Mismatch:
620
• When this error occurs in MC toners:
MC Toner Regional Mismatch:
621
Fatal
<nnn>
Power Off/On
%ERRCODE% : Fatal
Error
A fatal error occurred.
For more information, see "Service Calls List".
nnn: specifies 3 digits error code.
The message of fatal error is specifiedby English only.
Fatal
<nnn>
Inspection is required.
%ERRCODE% : Fatal
Error
A fatal error occurred.
For more information, see "Service Calls List".
nnn: specifies 3 digits error code.
The message of fatal error is specifiedby English only.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
