Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
314 /
7. Troubleshooting
Display Cause Error details Measure
Ask for inspection
by Oki Data.
181: Fatal Error
182: Fatal Error
Option unit I/
F error (181
=Duplex
Unit, 182 =
Option Tray)
Does the error recurr?
Does the error recurr?
Yes
Yes
Turn OFF the power
once and back ON.
Check for sure
connection of the
connector.
Replace the option unit.
Restart the MFP.
190: Fatal Error
System
memory
overflow. Does the error recurr? Yes
Turn OFF the power
once and back ON.
Install the add-on RAM
DIMM
Ask for inspection
by Oki Data.
200: Fatal Error
:
202: Fatal Error
PU
Firmware
Download
Error
Error has occurred during
PU firmware re-writing.
Turn OFF the power
once and back ON.
Then, download it
again. (This trouble
does not occur during
normal operation
because this process is
not used in the normal
operation.)
Restart the MFP.
203: Fatal Error
***
204: Fatal Error
***
207: Fatal Error
208: Fatal Error
214: Fatal Error
F0C: Fatal Error
F0D: Fatal Error
FFF: Fatal Error
FFE: Fatal Error
CU program
error.
(Errors
203 to 214
does not
occur during
normal
operation.)
CU program executed illegal
process.
Turn the power OFF.
Then, check connection
between CU PCB and
PU PCB. Turn OFF the
power once and back
ON.
Restart the MFP.
209: Download
error
Custom
Media
Type table
download
has failed.
Custom Media Type
downloading has failed.
Turn OFF the power
once and back
ON. Then, perform
downloading again.
(This trouble does not
occur during normal
operation because this
process is not used in
the normal operation.)
Display Cause Error details Measure
Ask for inspection
by Oki Data.
230: Fatal Error
RFID
Reader not
lnstalled
RFID read device error
Does the error recurr?
Yes
Yes
Check connections of
the RFID R/W PCB.
Replace the RFID R/W
PCB and replace the
P6X PCB.
Ask for inspection
by Oki Data.
231: Fatal Error *
I/F error of
RFID reader
I/F error between the RFID
reader is detected.
01: Communication error
between the RFID reader
and Engine PCB
02: Wireless circuit error of
RFID reader
03: Communication eeor
btwenn RFID reader and
tag chip
04: Error is detected in the
RFID tag chip. (In 4 or
more chips)
01: Same as the error
230
02: Replace the RFID
R/W PCB.
03: Check for correct
connection of
antenna cable.
04: Check that number
of the RFID tags is
correct.
Restart the MFP.
901: Fatal Error
:
904: Fatal Error
Belt tem-
perature is
abnormal.
901: Short-
circuit.
902: Open-
circuit.
903: High
temper-
ature.
904: Low
temper-
ature.
Is the cable between the belt
thermistor and high voltage
PCB connected normally?
Does the error recurr?
No
Yes
No
Re-connect the cable
normally.
Turn OFF the power
once and back ON.
Belt thermistor
replacement
Restart the MFP.
918: Fatal Error
Duplex
FAN Alarm
Dtekution
Duplex internal FAN error.
Does the problem recur after
turning OFF the power once
and back ON?
Does the problem recur after
turning OFF the power once
and back ON?
Yes
Yes
Check that the Duplex
unit is installed
normally.
Check that the FAN is
connected normally.
Replace the FAN.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
