43967002TH Rev.1

71 /

Oki Data CONFIDENTIAL

3. Installation

Two screws

6. Fix the main unit to the add-on tray unit tightly.

Tighten securely the 8 screws that were loosened in step 5, and 0.8 screws that were

tightened only temporarily in step 5, totaling 16 screws with force.

Left side

Screw

Tighten the two screws at the deep end

on the right side by performing steps

and .
